Laser System환경 설정
System specifications: Power: ≤ 30 W. Pulseshape temp.:≥ 10 ns. Pulse to Pulse stability: ± 12 %. Beam divergence: ≤ 0.2 mrad. Bandwidth(T mode): ≤3 pm. Tuning range (T mode): ≥ 0.4 nm Pulse length: ~ 20ns PC control. Laser medium: ArF (193 nm), KrF (248 nm), XeCl (308 nm) CDRH-class (laser classification): IV Dimensions w/out computer: (L x H x W): 1960 x 1350 x 828 mm³ Weight: 875 kg Two separately charged and switched laser heads built as single unit. Choice of operations: a)Oscillator-Power-Amplifier (OPA) Mode b)Tuning Mode c)Two-Color Mode at pulse energies up to 500 mJ and repetition rates up to 50 Hz. All modules of system contained within laser cabinet. Wheels on unit for easy movement to different operating sites. Extra space available for optional halogen gas generator and 50-liter premix gas bottle.OEM 모델 설명
미제공문서
문서 없음
LAMBDA PHYSIK
COMPEX 150
검증됨
카테고리
Laser
마지막 검증일: 60일 이상 전
주요 품목 세부 정보
조건:
Used
작동 상태:
알 수 없음
제품 ID:
22738
웨이퍼 사이즈:
알 수 없음
빈티지:
1997
Have Additional Questions?
Logistics Support
Available
Money Back Guarantee
Available
Transaction Insured by Moov
Available
Refurbishment Services
Available
LAMBDA PHYSIK
COMPEX 150
카테고리
Laser
마지막 검증일: 60일 이상 전
주요 품목 세부 정보
조건:
Used
작동 상태:
알 수 없음
제품 ID:
22738
웨이퍼 사이즈:
알 수 없음
빈티지:
1997
Have Additional Questions?
Logistics Support
Available
Money Back Guarantee
Available
Transaction Insured by Moov
Available
Refurbishment Services
Available
설명
Laser System환경 설정
System specifications: Power: ≤ 30 W. Pulseshape temp.:≥ 10 ns. Pulse to Pulse stability: ± 12 %. Beam divergence: ≤ 0.2 mrad. Bandwidth(T mode): ≤3 pm. Tuning range (T mode): ≥ 0.4 nm Pulse length: ~ 20ns PC control. Laser medium: ArF (193 nm), KrF (248 nm), XeCl (308 nm) CDRH-class (laser classification): IV Dimensions w/out computer: (L x H x W): 1960 x 1350 x 828 mm³ Weight: 875 kg Two separately charged and switched laser heads built as single unit. Choice of operations: a)Oscillator-Power-Amplifier (OPA) Mode b)Tuning Mode c)Two-Color Mode at pulse energies up to 500 mJ and repetition rates up to 50 Hz. All modules of system contained within laser cabinet. Wheels on unit for easy movement to different operating sites. Extra space available for optional halogen gas generator and 50-liter premix gas bottle.OEM 모델 설명
